MHS2, Air Gripper, 2 Finger, Parallel Style – MHS2-32D
€453,05
Skip to product information
MHS2, Air Gripper, 2 Finger, Parallel Style – MHS2-32D
€453,05
VAT not included.
- The MHS is the latest in the family of rotary operated parallel style grippers. This compact gripper is available in 10 different bore sizes with choices of 2, 3 and 4 fingers which generate gripping forces up to 1270 N. Pinholes are incorporated as standard, facilitating accurate mounting which is achieved through either body tapped or through-hole mounting. By using a wedge cam construction to attach the fingers to the rotary actuator a more compact design is achieved, as well as high repeatability of 0.01 mm. Auto switches can be simply attached via the standard built-in grooves
Key features
- 2 finger parallel style air gripper
- Two fingers
- Bore sizes: 16, 20, 30, 32, 40, 50, 63 (mm)
- Auto switch capable
Specifications
- Bore Size: 32mm
- Auto Switch: No Switch
- Lead Wire or Prewired Connector: 0.5m (Or None in the Case of No Switch)
- Number: 2 pcs. (Or None in the Case of No Switch)
Additional information
- Part number: MHS2-32D
- Lead time (days): 5
- Minimum order quantity: 1
- Country of origin: JP
- TARIC code: 8479899790
