JA, Floating Joint, Standard – JA160-36-150
€321,95
Skip to product information
JA, Floating Joint, Standard – JA160-36-150
€321,95
VAT not included.
- The floating joint series JA (standard) and JAH (heavy duty), can absorb any "off-centering" or "loss of parallel accuracy" between the cylinder and the driven body. Because of this, centering is unnecessary, installation time is drastically reduced, and a high level of machining accuracy is unnecessary.
Key features
- Standard/Thread nominal size
- Mountings: basic, flange, foot
- Eleven model options available
- Centering is unnecessary
- Rotation angle: ¹5°
Specifications
- Mounting: Basic Style
- Applicable Bore Size: 160 mm
- Nominal Thread: 36-150 (M36 x 1.5)
- Option: None
Additional information
- Part number: JA160-36-150
- Lead time (days): 5
- Minimum order quantity: 1
- Country of origin: JP
- TARIC code: 8479899790
